• Product description

  • The X3-Hybrid three-phase hybrid inverter converts the energy from solar panels into alternating current and then stores it in batteries.
  • This allows the energy to be used at a later date, to optimize your own electricity consumption, or to supply energy to the public grid.
  • The inverter can be connected to Wi-Fi and controlled remotely.
  • Support up to 150% oversizing on DC input.
  • High-performance energy recovery.
  • High IP65 protection.
  • Maximum device performance even in extreme temperatures.
  • X3-hybrid-15.0-D (G4):
    X3 = three-phase;
    Hybrid = series;
    15.0 = 15.0 kW;
    D = with DC switch.
  • Number of phases: 3.
  • Number of MPPT: 2.
  • MPPT voltage range: 180 - 950 V.
  • Rated AC power: 15000 W.
  • Max DC power: 18000 Wp.
  • Max. input current input A/ input B: 26/14 A.
  • Max. short-circuit current input A/input B: 30/16 A.
  • Max. output current AC: 24.1 A.
  • Battery type: Lead/Lithium.
  • Battery voltage range: 180 - 650 V.
  • Recommended battery voltage: 400 V.
  • Max. continuous/discharge current: 30 A.
  • A firmware update is required during installation.

  The catalog sheet and operating instructions can be found in the downloadable documents below.


  Please note that installation and dismantling of solar panels and solar accessories must be carried out by a qualified person.

  Brand:

  SolaX Power
