• Product description

  • Surge protection with QS technology designed for installation on a DIN rail.
  • Number of poles: 3 (L1, L2, L3).
  • Type of surge arrester: T1-T2.
  • Impulse current limp (10/350): 12.5 kA.
  • Maximum impulse discharge current Imax (8/20): 80 kA.
  • Rated impulse discharge current In: 30 kA.
  • Rated voltage Un: 230/400 V AC.
  • Maximum continuous operating voltage Uc: 275 V.
  • Protection level: 1.1 kV.
  • Maximum cross-section of solid/stranded conductor: max. 50 mm².
  • Maximum cross-section of fine conductor: max. 35 mm².
  • Tightening torque: 3.5 Nm.
  • Degree of protection: IP20.

  Special coupon offer applies to this product.

  Brand:

  ABB
